I started a Crazy project - Big ray habitat

Filtration, lightning, heating, DIY, aeration, etc.

Moderator: Kev

Topic Rating:
  • Not rated


I started a Crazy project - Big ray habitat

Berichtdoor Royalray » di 24 jun 2008, 20:24

I started a crazy project - Big ray habitat

Hello all, I got into stingray since March 2007, and get more and more crazy about it. I have more than 100pcs now and i am running out of space to hold them, some are 40cm already, i have 10pcs pearl, 5pcs p14, 17pcs P13, 6pcs flower ray, 1 pcs tiger ray and over 80pcs marbled motoro. They grow bigger from day to day and some begin to breed, so i am seriously run out of space for them. I have dedicated a double storey house for all my rays, now i am building this crazy tank project for them.....

Afbeelding

Afbeelding

Afbeelding

Afbeelding

Afbeelding

Afbeelding

my ray habitat project started on 22nd May 2008, the whole idea is to make a good water system for all my ray, will be simulating to their nature environment, this tank is located outdoor and get sunshine all days, with water fall and small river system, total water capacity will be about 300,000 Liters waters. will have 6x 3.5m x 7m x 1m, 12x 3.5m x 3.5m x 0.8m, 4x 1.4m x 7m x 1m, 2x 5m x 1m x 1m, and a big storage pond in the system that hold 100,000L water.

any idea what should i use for the water filter? my water filter chamber will be 1.2m (width) x 20m (lenght) x 1m (height). dividing into few partition with each partition about 3.5m lenght. i plan to use a ultra sieve filter for koi pond that will automatically remove all the solid waste before come into the biological filter chamber. I am thinking to include water plant in few of the partition. and use the brush for the biological system.

can any expert pls give me some input? i need the filter system to be super efficient as i think this is the most important part of the ray habitat's requirement.

any input will be greatly appreciated....

Enjoy the photo of my crazy project .... ;-)

Afbeelding

Afbeelding

Afbeelding

Afbeelding

Afbeelding

Afbeelding

Afbeelding
Avatar gebruiker
Royalray
Nieuw lid

Berichten: 19
Geregistreerd: di 24 jun 2008, 20:20

Re: I started a Crazy project - Big ray habitat

Berichtdoor Haiko » di 24 jun 2008, 20:29

Super nice project bro.

If you want good and relative cheap filtration i would use settling tanks and trickling towers, maybe some fluidized bed filters and a nitrate reactor if needed. best material for trickling towers are crossflowblocks.
Avatar gebruiker
Haiko
Actief lid

Berichten: 1347
Geregistreerd: vr 22 feb 2008, 13:58
Woonplaats: Wageningen

Re: I started a Crazy project - Big ray habitat

Berichtdoor Lode » di 24 jun 2008, 20:39

Fantastic project!

Some of my imput:
  • I would use a very large (high) wet dry filter system.
  • Probably any filter medium that has as much surface area as possible is good, as long as it doesn't affect pH. Be sure to aerate the dry filter tower as much as possible and the higher the better. Ceramic is very good (for instance Alpha rock), but they say it may deteriorate in time. However, I haven't seen it in my system. Bio ring is good, but has much less surface.
  • Multiple towers sounds good, maybe one very big (high) one is better then many smaller ones. However several ones give redundancy.
  • You could also go for a fluidized bed filter. With fluidized bed I mean a moving filtermedium filter. For instance, a moving sand filter or Kaldness is used a lot lately in the koi systems. *


Edit:
* Aquarium fluidized bed filters are supplemental filters that can make a great addition to a large, heavily stocked aquarium. By "fluidizing" or suspending fine grained media in a column of water, they increase surface area and contact time for highly efficient biological filtration. Aquarium fluidized bed filters are ideal for planted aquariums, as they won't wear off your CO2. They are easy to maintain and you won't disturb your bacterial bed, which is a problem with some biological filters. Use caution: they are a potential nitrate hazard during long power failures.

Fluidized bed reactors use the same process to suspend chemical media in a column of water with the same boosts to efficiency, for advanced chemical filtration needs.
Avatar gebruiker
Lode
Beheerder

Berichten: 12210
Geregistreerd: vr 15 feb 2008, 17:54
Woonplaats: Meerkerk

Re: I started a Crazy project - Big ray habitat

Berichtdoor Haiko » di 24 jun 2008, 20:44

trickling towers can best be filled with lightweight plastic medium. the stuff im talking about has proven to be superb to most other media and is very cheap. it doesnt clog either. trickling towers can easily be made of stainless steel frame and agricultural plastic canvas. extra aeration is not needed as they are open at the top and bottom.

i would deffo go for multiple towers if possible so you can seperate your tanks in case of disease or something nasty.

if you build good settling tanks you will not need any fluidized filters as all big particles will be removed before entering the trickling tower.
Avatar gebruiker
Haiko
Actief lid

Berichten: 1347
Geregistreerd: vr 22 feb 2008, 13:58
Woonplaats: Wageningen

Re: I started a Crazy project - Big ray habitat

Berichtdoor Bobbie » di 24 jun 2008, 21:06

amazing project ! keep us updated with alot of pics :D
Avatar gebruiker
Bobbie


Re: I started a Crazy project - Big ray habitat

Berichtdoor cooldown77 » di 24 jun 2008, 21:52

Wow this is really a BIG project.......hope to see more pics soon :duim
Avatar gebruiker
cooldown77
Actief lid

Berichten: 757
Geregistreerd: ma 25 feb 2008, 20:09
Woonplaats: Enschede

Re: I started a Crazy project - Big ray habitat

Berichtdoor Broek » di 24 jun 2008, 22:13

Whoowwwww really nice work mate!!

Where are you located? Maybe a really good spot for another forum meeting :-?

Please keep us updated with lots of pictures!
Avatar gebruiker
Broek
Actief lid

Berichten: 292
Geregistreerd: ma 03 maart 2008, 16:47
Woonplaats: Den Haag

Re: I started a Crazy project - Big ray habitat

Berichtdoor mb_barton » di 24 jun 2008, 23:11

wow dude! this is totally awesome! I wish i had my own house to do something like this. for now my "small" tanks will have to do..

but definitly keep us posted!
Avatar gebruiker
mb_barton
Actief lid

Berichten: 40
Geregistreerd: wo 19 maart 2008, 21:09

Re: I started a Crazy project - Big ray habitat

Berichtdoor Robbert » di 24 jun 2008, 23:24

Wow that looks very promising! Keep us posted!
:D
Avatar gebruiker
Robbert
Erelid

Berichten: 599
Geregistreerd: wo 05 maart 2008, 02:28
Woonplaats: USA

Re: I started a Crazy project - Big ray habitat

Berichtdoor flemming » di 24 jun 2008, 23:33

thats going to be a lot of water
Avatar gebruiker
flemming
Actief lid

Berichten: 887
Geregistreerd: zo 02 maart 2008, 21:06
Woonplaats: Leeuwarden
